Description
| Brand | HIKVISION |
| Video format | HDTVI / HDCVI / AHD / CVBS / IP |
| Video inputs | 1632Canales BNC, (HDTVI / HDCVI / AHD / CVBS) |
| Hybrid configuration | 16 Additional IP CH: Up to 48 IP channels (6 Mpx), replacing all BNC channels |
| Available bandwidth | 200 Mbps input 160 Mbps output |
| Video outputs | 1 HDMI 4K, 1 HDMI 1080p and 1 VGA (HDMI 4K and VGA independent, HDMI 1080p and VGA simultaneous); 1 BNC CVBS |
| Display resolution | HDMI 4K: 3840×2160 (4K) / 30 Hz;, 2560×1440 (2K), 1920×1080, 1280×1024, 1280×720, 1024×768 / 60Hz HDMI 1080p: 1920×1080, 1280×1024, 1280×720, 1024×768 / 60Hz VGA: 1920×1080, 1280×1024, 1280×720, 1024×768 / 60Hz CVBS: 704×576 (PAL) / 704×480 (NTSC) |
| Audio inputs | 4 Channel RCA |
| Audio outputs | 1 Channel RCA |
| Bidirectional audio | Reusing the audio input |
| Audio Bit Rate | 64 Kbps |
| Audio compression | G.711u |
| Video compression | Analog: H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264 IP: H.265+ / H.265 / H.264+ / H.264 |
| Input resolution | HDTVI: 4Mpx,1080p (25~30 fps), 720p (25~60 [%VAR%] fps) HDCVI: 1080p (25~30 fps), 720p (25~30 [%VAR%] fps) AHD: 4Mpx,1080p (25~30 fps), 720p (25~30 [%VAR%] fps) CVBS: PAL/NTSC |
| Main Stream coding | 1080P Lite not enabled Stream of 4MPx: 4 Mpx Lite@15 FPS; 1080p lite/720p/WD1/4CIF/VGA/CIF@25 FPS (P)/30 FPS (N) Stream of 1080p: 1080p/720p@15 FPS; VGA/WD1/4CIF/CIF@25 FPS (P)/30 FPS (N) Stream of 720p: 720p/VGA/WD1/4CIF/CIF@25 FPS (P)/30 FPS (N)1080P Lite enabled 4 Mpx lite@15 FPS; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25 FPS (P)/30 FPS (N) |
| Extra Stream coding | WD1/4CIF@12FPS; CIF@25 FPS (P)/30 FPS (N) |
| Video Bit Rate | 32 Kbps at 6 Mbps |
| Simultaneous multifunction | Pentaplex: Live, Recording, Playback, Backup and Remote Access |
| Alarms | 16 inputs / 4 relay |
| POS | Yes |
| Recording method | Manual, programmed, motion detection |
| Backup | USB (Memory, HDD, CD-RW, DVR-RW) / Network |
| Internal memory | 4 HDD SATA 3.5″ of up to 12 TB each (not included) |
| Communication | 3 x USB (Mouse and backup) / 2 x RJ45 (Ethernet) / 1 x RS-485 full-duplex / 1 x RS-232 / 1 x e-SATA |
| Remote connections | 128 |
| Remote access | Web Browser, Hik-Connect Smartphone App, PC Software iVMS-4200 and Hik-Central |
| Power | AC 100~240 V, ≤ 40 W (without HDD) |
| Operating temperature | -10° ~ +55° C |
| Dimensions / Weight | 445 (W) x 400 (D) x 71 (H) mm / ≤ 7 Kg (w/o HDD) |
