Description
| n Specification | |
| Camera | |
| Image Sensor | 3K CMOS |
| Signal System | PAL/NTSC |
| Max. Resolution | 2960 (H) × 1665 (V) |
| Min. Illumination | 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light |
| Shutter Time | PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s |
| Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360° |
| Lens | |
| Lens Type | 2.8 mm and 3.6 mm fixed focal lens |
| Focal Length ＆ FOV | 2.8 mm, horizontal FOV: 110°, vertical FOV: 59°, diagonal FOV: 139° 3.6 mm, horizontal FOV: 90°, vertical FOV: 49°, diagonal FOV: 105° |
| Lens Mount | M12 |
| Illuminator | |
| Supplement Light Range | IR: Up to 20 m,White Light: Up to 20 m |
| Smart Supplement Light | Yes |
| Image | |
| Frame Rate | 3K @20 fps, 4 MP @25 fps/30 fps, 1080p @25 fps/30 fps |
| Wide Dynamic Range (WDR) | ≥130 dB |
| Image Parameters Switch | STD/HIGH-SAT/HIGHLIGHT |
| AGC | Yes |
| Day/Night Mode | Auto/Color/BW (Black and White) |
| White Balance | Auto/Outdoor/Global/Manual |
| Image Enhancement | WDR,BLC,HLC,Global,HLS |
| Noise Reduction | 3D DNR/2D DNR |
| Image Settings | Brightness,Contrast,Mirror,Smart Light,Anti-Banding |
| Interface | |
| Video Output | 1 HD analog output |
| Event | |
| Motion Detection | 4 programmable motion areas |
| General | |
| Power | 12 VDC ± 25%, 0.47 A, max. 5.7 W,*You are recommended to use one power adapter to supply the power for one camera. |
| Language | English |
| Operating Condition | -40 °C to 60 °C (-40 °F to 140 °F). Humidity: 90% or less (non-condensing) |
| Material | Metal |
| Communication | HIKVISION-C |
| Dimension | 161.1 mm × 68.4 mm × 65.2 mm (6.34″ × 2.69″ × 2.57″) |
| Weight | Approx. 405 g (0.89 lb.) |
| Approval | |
| Protection | IP67 |
